What Is a Fence Site Plan?

A fence site plan is a scaled property drawing showing exactly where a proposed or existing fence is located. It identifies the property boundaries, fence segments, gates, fence height and material, existing buildings, driveways, streets, easements, and other site conditions relevant to the permit review.

Building and zoning departments use the plan to evaluate whether the fence complies with location, height, visibility, access, easement, right-of-way, pool-barrier, and zoning requirements. Corner lots, waterfront properties, pool enclosures, commercial sites, and properties with unusual boundaries may require additional information.

We prepare fence site plans using the property survey, proposed fence sketch, contractor proposal, photographs, property records, and project information supplied by the client. If a certified survey, structural fence design, engineering, or professional seal is required, we can identify that need during the project review.

Fence rules often change between the front, side, and rear yards. Corner lots may have two street-facing yards and special visibility restrictions. The complete property layout should be reviewed before the fence line is finalized.

WHO WE SUPPORT

Who Needs a Fence Site Plan?

Homeowners

Planning a privacy fence, pool barrier, replacement fence, or new gate? We turn your survey and fence information into a clear site plan for the permit application.

→ Order Pool Permit Site Plan — $149

Fence Contractors and Installers

Send us the customer's survey, project address, proposed fence line, material, and height. We provide consistent site plan drafting for individual or recurring projects.

→ Order Fence Permit Site Plan — $79

Builders and Developers

We coordinate fencing with new homes, subdivisions, pools, outdoor-living areas, driveways, utilities, landscaping, and site improvements.

→ Order Shed Permit Site Plan — $79

Commercial Property Professionals

Property managers, business owners, architects, engineers, and permit coordinators can use our team for commercial fence, security gate, and enclosure plans.

→ Order Deck / Porch Site Plan — $99

Fence Site Plans for Residential and Commercial — Projects

We prepare site plans for new fences, replacements, relocations, pool barriers, gates, commercial enclosures, and after-the-fact applications.

Fence Site Plans for Residential and Commercial Projects
Project Type	Typical Site Plan Scope	Additional Coordination
Residential privacy fence	Fence line, height, material and gates	Front, side and rear-yard restrictions
Wood fence	Fence location, height, gates and property relationship	Post or wind details may apply
Vinyl fence	Fence layout, height and gate locations	Manufacturer information may be required
Chain-link fence	Fence line, height, gates and proposed use	Screening requirements may apply
Aluminum or ornamental fence	Fence layout, height and opening locations	Pool-barrier rules may apply
Pool barrier fence	Fence, gates, pool, deck and access points	Barrier and gate-compliance notes
Front-yard fence	Fence line, height, driveway and street relationship	Visibility and height restrictions
Corner-lot fence	Street frontages, fence height and visibility area	Sight-distance review may apply
Replacement fence	Existing and proposed fence information	Nonconforming conditions may require review
Fence relocation	Existing and proposed fence lines	Survey and setback verification
Fence with driveway gate	Gate width, swing or slide direction and access	Vehicle visibility and gate automation
Dumpster or equipment enclosure	Enclosure, gates and service access	Screening and material requirements
Masonry wall or solid fence	Wall location, height and openings	Foundation and structural engineering
Coastal or high-wind fence	Fence layout, height and material	Wind-load design may be required
Waterfront fence	Fence location relative to water and easements	Environmental or waterfront approval
Agricultural or rural fence	Property perimeter, gates and access	Large-property or survey coordination
After-the-fact fence	Existing fence line, height and gates	Legalization or correction drawings

Simple rule: A standard fence site plan shows the proposed fence's location on the property. Post, footing, wind-load, masonry-wall, gate-operator, electrical, structural, or engineered details are separate services unless specifically included in the proposal.

WHAT YOUR DRAWING MAY INCLUDE

What Every Fence Permit Site Plan Should Show

The exact requirements vary by jurisdiction, fence type, property configuration, and intended use. A typical fence site plan may include the following information.

Property & Existing Conditions

Proposed Fence Layout

Gates & Access

Zoning & Visibility

Easements & Utilities

Pool Barrier Information
